Skyzone SKY04X 5.8G 48CH 1280*960 OLED FPV Goggles with Steadyview Receiver DVR Head Tracker Function
Skyzone SKY04X 5.8G 48CH 1280*960 OLED FPV Goggles with Steadyview Receiver DVR Head Tracker FunctionSkyzone SKY04X 5.8G 48CH 1280*960 OLED FPV Goggles with Steadyview Receiver DVR Head Tracker FunctionSkyzone SKY04X 5.8G 48CH 1280*960 OLED FPV Goggles with Steadyview Receiver DVR Head Tracker FunctionSkyzone SKY04X 5.8G 48CH 1280*960 OLED FPV Goggles with Steadyview Receiver DVR Head Tracker FunctionSkyzone SKY04X 5.8G 48CH 1280*960 OLED FPV Goggles with Steadyview Receiver DVR Head Tracker Function

Skyzone SKY04X 5.8G 48CH 1280*960 OLED FPV Goggles with Steadyview Receiver DVR Head Tracker Function

Item# BA0057
USD $499.99
Color:
RedWhiteBlackGrey
QTY:
Coming Soon

The Skyzone SKY04X is the newest OLED FPV goggle released by Skyzone and it is the first skyzone goggle with focus adjustment. Skyzone SKY04X goggle comes with the 1280*960 high resolution screen, which has vivid color and high contrast ration, pilot can see more details in the racing.
SKY04X FPV goggle comes with the 5.8G 48CH SKY-FUSION receiver, the receiver merge two signal to one, avoid image tearing and rolling, which makes the image more stable and clear in challenging condition.
The new designed optics have focus adjustment feature and 46 degree Field of view, gives pilots more immersive FPV experience.It also supports DVR funactoon that SD card support up to 128GB,and Type C connector to upgarde the firmware or power goggle.

Specifications:
Brand: SKYZONE
Model: SKY04X
Item: 5.8GHz 48CH SKY-FUSION Receiver 1280X960 FPV Goggles
Screen: OLED
Resolution: 1280X960
FOV (Diagonal): 46°
AspectRatio: 4:3/16:9
Focus: -6~+6 adjustable
Interpupillary distance(IPD): 58-71mm
Receiver: 5.8Ghz 48CH SKY-FUSIONReceiver
Language: 10 Language
Power Supply: DC6.5-25.2V/USB5V
PowerConsumption: 720mAat12V
DVR: H264,30fps,MOV6Mbps,SD Card support up to128Gb
Head Tracker: 3-axis Accelerometer, 3-axisgyroscope
Dimentions: 185*75*67mm
Weight: 267g

Package Included:
1x Skyzone SKY04X OLED FPV  Goggles
1x Receiver Module
2x Faceplate (wide and narrow)
1x Sponge with velcro
1x Zipper case
1x Power cable
1x Headtracker cable
2x 5.8GHz 2dD antennas
1x Video/Audio Cable
1x USB-C Cable
1x Uer Manual


Skyzone SKY04X User Manual
