HGLRC ZEUS VTX 2.5W 5.8G High Power Image Transmission Adjustable Power Aerial Photography Travel FPV
Item# HGLRC-VTX
USD $49.99
DESCRIPTION
REVIEWS
The HGLRC ZEUS VTX 2.5W VTX is adjustable power that 6 power levels is adjustable PIT/25mW/200mW/800mW/1600mW/2500mW .The MAX range is about 10KM.It is wonderful vtx for Aerial Photography and racing drone.
Features: 1.The actual measured distance when flying near a lake is 9 kilometers under interference in urban environment, and it can easily fly more than 10 kilometers in suburban/mountainous environment. 2.2500mW high power, maintaining sufficient power output, suitable for long range and ultra-long distance flights. 3.6 power levels adjustable PIT/25mW/200mW/800mW/1600mW/2500mW. 4.CNC integrated upper and lower shell covering structure, strong heat dissipation effect, maintaining stable performance. 5.Dual-function buttons make parameter adjustment easier, and 3 sets of LED indicators display power/frequency group/frequency points at a glance. 6.Supports IRC Tramp protocol OSD parameter adjustment. 7.Supports 2-6s (7-26V) wide voltage input. 8.Supports 30.5x30.5 M3 hole installation.
Specification: Product name: Zeus VTX 2.5W Support voltage: DC 7-26V (2-6S) BEC: 5V/800mA Antenna interface: MMCX Cable interface: GH1.25 6P Video format: PAL/NTSC Standard 40 channels: A/B/E/F/R frequency group Protocol: IRC Tramp Output power: PIT/25/200/800/1600mW/2500mW PitMode/0dbm 25mW/13.95dBm 200mW/23.01dBm 800mW/29.03dBm 1.6W/32.04dBm 2.5W/33.98dBm Installation hole position: 30.5*30.5*M3 Dimensions (L*W*H): 40mm x 35mm x 11.8mm Weight: 19.6g
Package Includes: 1x Zeus VTX 2.5W 1 x MMCX 80mm copper tube antenna 1 x MMCX to SMA 100mm adapter 1 x GH1.25 6Pin 100mm single-ended cable 1 x SH1.0 4Pin-GH1.25 6Pin 60mm double-ended cable
